VIDEO RECORDER 3 CHANNELS MOBILE HDCVI MCVR5104
The first 4-channel mobile HDCVI-capable video recorder can support 1080P high-definition recording in real-time, support the actual vehicle position and tracking. All information such as GPS and video can be downloaded from a 3G / 4G / WIFI wireless network.
-Support HDCVI/Analog Video input
-H.264 dual-stream video compression
-Support 2 ch 1080P+2 ch 720P realtime recording
-VGA/TV simultaneous video output
-Support 1 SATA HDD, 2 USB2.0
-Aviation connectors adopted
-Multiple monitoring: Web viewer, CMS(DSS) & DMSS
-
System
Main Processor
Embedded microprocessor
Operating System
Embedded LINUX
Audio and Video
Input
4 Channel (Don’t support audio in when connecting
analog cameras)
Two-way Talk
1 Channel Input, 1 Channel Output, RCA
Display
Interface
1VGA, 2T V
Resolution
1920×1080, 1280×1024, 1280×720, 1024×768,
800×600
Display Split
1/4
Privacy Masking
4 rectangular zones (each camera)
OSD
Camera title, Time, Video loss, Camera lock, Motion
detection, Recording
Recording
Video/Audio Compression
H.264/G.711
Resolution
2ch@1080P+2ch@720P(1~25/30fps)
Bit Rate
48~8192Kb/s
Record Mode
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec,
Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer &
Screen tips
Video Detection
Motion Detection, MD Zones: 396(22×18), Video
Loss & Camera Blank
Alarm input
7 channel
Relay Output
2 channel
Playback and Backup
Playback
1
Search Mode
Time/Date, Alarm, Motion Detection & Exact search
(accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow play, Next
file, Previous file, Next camera, Previous camera,
Full screen, Repeat, Shuffle, Backup selection,
Digital zoom
Backup Mode
USB Device/Network
Storage
Internal HDD
1 SATA Ports, Up to 2 TB capacity
SD card
1 SD card, Up to 128 GB
