MICROPHONE DH-HAP200
Microphone of very good quality plastic and easy to install.
- Plastic material
- Easy to install
- ALC processing circuit
- Basic noise reduction
- Support cascading
-
Scope 10~100 m^2
Sensitivity
-30dB
Frequency response
20Hz～20kHz
Directional characteristic
Omni-directional
SNR80dB(1m 40dB sound source SPL)50dB(10m 45dB sound source SPL)1kHz at 1Pa
Dynamic range
104dB(1KHz at Max dB SPL)
Max. sustainable sound pressure
120dB SPL(1KHz, THD 1%)
Output impedance
600Ω(non-equilibrium)
Output signal amplitude
2.5Vpp/-25dB
Microphone
Electret condenser microphone
Working voltage
DC 12V(9~18V)
Working current
50mA
Working temperature
-25ºC~+70ºC(-13℉~+158℉)
Material
PC+ABS
Color
White+silver
Dimension
79.6mmx79.6mmx21.5mm (3.13”x3.13” x0.85”)
Weight
0.06kg(0.13lb)
Certification
CE/FCC
