OPTICAL FLAP TURNSTILE DAOSAFE DS3000
With the DS3000 gates, you ensure secure and fast passage. Suitable for indoor and outdoor areas such as colleges, offices, and buildings. They support a throughput rate of 40-45 persons per minute. Made from stainless steel, they feature an arc design without angles to prevent accidents and a long LED indicator.
-
The DS3000 high-speed gates offer reliable and fast access for indoor and outdoor spaces. They are made from stainless steel with black painting for aesthetics and durability. The arc-shaped design without angles prevents injuries. The system features a long, slim LED indicator bar at the front and a top-side LED indicator for entry acceptance or denial. Supporting a throughput rate of 40-45 persons per minute, they also have 4 pairs of infrared sensors for security. The gates can be set for single or bi-directional passage.
Key Characteristics
Model number: DS3000
Brand: Daosafe
Framework Material: 304 Stainless Steel
Arm Material: Plexiglas - transparency
Dimension: 1400 * 280 * 1000mm
Weight: 70kg/pcs
Passage Width: 550 - 900mm (One passage)
Passing Direction: Single directional / Bi-directional
MCBF: 5 million
Power Supply: AC220V/110V, 50/60Hz
Operation Voltage: 24V DC
Power Consumption: 40W
Operation Temperature: -15 °C - 60 °C
Operation Humidity: 0 ~ 95% (No freeze)
Working Environment: Indoor / Outdoor
Flow Rate: 40-45 people per minute
LED Indicator: Yes
Infrared Sensor: 4 pairs (standard)
Emergency: Automatic arm open when power off
Communication: Dry contact, Relay signal, RS485
Related Files
-
3178_DS-3000-removebg-preview (1)!!.png (152.07 kb)
3193_Daosafe-DS3000-Optical-Flap-Turnstile-DatasheetF.pdf (1988.67 kb)
-
