TURNSTILE 3 WINGS ELECTROMECHANIC SINGLE INOX T-345
T-345 tripod turnstile provides the basic access control solution to secure various locations worldwide. The mechanism is manufactured to ensure long years of trouble free use, especially for locations with intense passage flows.
T 345 can be installed in various locations like public transportation terminals, universities, banks, ministries, business centers, museums and amusement parks etc.
-
SPECIFICATIONS
Control /Operation Voltage :
24VDC +-%20
Power Consumption :
30W
Tripod Locking :
With 24 V DC selenoids; lock when the selenoids are pulled.
Tripod Position Dedection :
Direction of the tripod position with two microswitches.
Motion Control :
When the cycle starts to one direction, the reverse is blocked and after a half turn the rest of the cycle is completed, automatically and smoothly by a hydraulic shock absorber.
Installation :
Simple & easy installation
Operation Temperature :
- 20° C - + 70° C
Indicators :
LED on both sides
Dimensions :
250x450x950 mm
Weight :
35 Kg
Optional Accesories :
Drop-arm, remote control, button unit,card reader,biometric reader,coin unit
T-345Related Products
Manufacturer: OZAK
Double turnstyle made entirely of steel. Coating of electrostatic paint on rotor, bar and turnstyle body. Manual and hydraulically silent immobilisation and vibration absorbing system.
It has 2 × 4 fins and 9 bars / fins. Locking system, anti-corrosion protection, available for indoor / outdoor installation (with special housing), allows two-way passage (for one person at a time), anti-roll bar, emergency release (from panic button activation or signal fire), authorized passage and intermittent flow for strict control of incoming
Flow rate min. 8 - max. 17 people / minute. Operation at temperatures from -17 ° C to + 68 ° C, compatible with all access control systems, operation and metal detecting systems.
Power supply 220V AC / 50Hz, 24-27V DC. Dimensions: 1860x1190x2260mm, Weight: 500 kg.
Optional: Countermeasurer (manual or electromechanical), weight sensor, manual control unit (with infrared or cable), alarm unit, card readers, moving lights, direction indicators, metal detector, computer interface unit, dividers, , etc. OZAK...
It has 2 × 4 fins and 9 bars / fins. Locking system, anti-corrosion protection, available for indoor / outdoor installation (with special housing), allows two-way passage (for one person at a time), anti-roll bar, emergency release (from panic button activation or signal fire), authorized passage and intermittent flow for strict control of incoming
Flow rate min. 8 - max. 17 people / minute. Operation at temperatures from -17 ° C to + 68 ° C, compatible with all access control systems, operation and metal detecting systems.
Power supply 220V AC / 50Hz, 24-27V DC. Dimensions: 1860x1190x2260mm, Weight: 500 kg.
Optional: Countermeasurer (manual or electromechanical), weight sensor, manual control unit (with infrared or cable), alarm unit, card readers, moving lights, direction indicators, metal detector, computer interface unit, dividers, , etc. OZAK...
Manufacturer: MAKIM
Excellent turbine type turnstyle rotor with stainless body ideal for controlling access to your space.
MAKIM T230 3Κ MOTORIZED VIP TURNSTILE
Stainless steel body
Dimensions (body) 230 x 990 mm
Dimensions (flap) 500 mm
Thickness (glass) 15 mm
Weight 35 kg
Two-way operation
Coil lock 24VDC
Electronic control board with programming functions...
MAKIM T230 3Κ MOTORIZED VIP TURNSTILE
Stainless steel body
Dimensions (body) 230 x 990 mm
Dimensions (flap) 500 mm
Thickness (glass) 15 mm
Weight 35 kg
Two-way operation
Coil lock 24VDC
Electronic control board with programming functions...
Manufacturer: MAKIM
The swing gates turnstyles, made with a top body, suitable for use in areas requiring access control.
MAKIM T230 MOTORIZED VIP TURNSTILE
Stainless steel body
Dimensions (body) 230 x 990 mm
Dimensions (flap) 800 mm
Thickness (glass) 15 mm plexiglass
Weight 35 kg
Two-way operation
Coil lock 24VDC
Electronic control board with programming functions...
MAKIM T230 MOTORIZED VIP TURNSTILE
Stainless steel body
Dimensions (body) 230 x 990 mm
Dimensions (flap) 800 mm
Thickness (glass) 15 mm plexiglass
Weight 35 kg
Two-way operation
Coil lock 24VDC
Electronic control board with programming functions...
