CARD PROXIMITY HID GLOSSY R/W   CARD PROXIMITY LEGIC 65BIT
MIFARE R/W

CARD PROXIMITY MIFARE R/W

MIFARE

MIFARE R/W

04.03.0004

IN STOCK

NXP has developed the MIFARE® MF1 IC S20 to be used in contactess smart cards according to ISO/IEC 14443A. The communication layer (MIFARE® RF Interface) complies to parts 2 and 3 of the ISO/IEC 14443A standard. The security layer sports the field proven CRYPTO1 stream cipher for secure data exchange of the MIFARE® Classic family.
This specification describes electrical, physical and dimensional properties of sawn wafers.

Contact for offer   Call us at +30 210-6148000
  • Favorite
  • Compare
  • Tell a Friend
  • Description
  • Features:
     > MIFARE® , RF Interface (ISO/IEC 14443 A)
        - Contactless transmission of data and supply energy (no battery needed)
        - Operating distance: Up to 100mm (depending on antenna geometry)
        - Operating frequency: 13.56 MHz
        - Fast data transfer: 106 kbit/s
        - High data integrity: 16 Bit CRC, parity, bit coding, bit counting
        - True anticollision
        - Typical access control transaction: < 50 ms (including backup management)

    > EEPROM
        - 320 Byte, organized in 5 sectors with 4 blocks of 16 bytes each (one block consists of 16 byte)
        - User definable access conditions for each memory block
        - Data retention of 10 years.
        - Write endurance 100.000 cycles

    > Security
        - Mutual three pass authentication (ISO/IEC DIS 9798-2)
        - Data encryption on RF-channel with replay attack protection
        - Individual set of two keys per sector (perapplication) to support multi-application with key hierarchy
        - Unique serial number for each device
        - Transport key protects access to EEPROM on chip delivery

    The chip completely compatible with NXP MIFARE Classic® 1K is FM11RF08. The performance of FM11RF08 is the same as NXP MIFARE Classic® 1K chip. As the price of NXP MIFARE Classic® 1K is relatively higher, so the FM11RF08 is used in many projects instead of NXP MIFARE Classic® 1K chip.
    NXP has developed the MIFARE® MF1IC MIFARE Classic® 1K to be used in a contactless smart card according to ISO/IEC 14443 Type A.
    The MIFARE® MF1IC MIFARE Classic® 1K IC is used in applications like public transport ticketing where major cities have adopted MIFARE® as their e-ticketing solution of choice.
    Chip Parameters

    Chip Type
    MIFARE Classic® 1K
    Frequency
    13.56MHz
    Supplier
    NXP
    Mode
    Read/Write
    Protocol
    ISO14443A
    Memory
    1K byte
    Operating Distance
    Up to 100mm (depending on antenna geometry)
    Anticollision
    YES
    Applications
    Public transportation, Access control, Event ticketing, Gaming&identity



    Card Parameters

    Dimention
    85.6×54×0.8 mm
    Material
    PVC, PET, ABS, PC, PETG
    Surface
    Matt / Glossy / frosted
    printing
    offset, silk-screen
    Temperature
    -25~50 ‘C
    Weight
    6 grams
    Package
    200 or 250 pcs/box, or on request
