ALARM CONTROL PANEL WIRELESS AJAX HUB2 PLUS

Hub 2 Plus makes external communication stability absolute. It has 4 communication channels and supports LTE. Such configuration allows you to connect the device to two separate Internet providers over Ethernet and Wi-Fi while having two cellular services ready for back up. Switching between channels happens seamlessly in seconds.

Alarm verification with photo in 9 seconds

Photo verification is the future of the security industry. This technology is an optimal solution for both commercial and residential premises — it is accessible and built to respect privacy. Animated series of photos from MotionCam detectors allow users and CMS operators to evaluate the situation in action. But photo cameras are activated only in response to alarms, never by request.

Hub 2 Plus can manage up to 200 MotionCam detectors and deliver photo confirmations of alarms to users and alarm monitoring companies in just 9 seconds, even when it uses SIM cards for communication. Thanks to LTE support.

Automated security

Hub 2 Plus supports 64 scenarios that minimize human impact on the security of a location. It can automatically arm and disarm the entire security system or certain groups by schedule. Moreover, it can instantly activate a smoke security machine in case of intrusion, cut power supply and turn on emergency lighting in case of fire, or cut water in case of leakage. Using automation devices, Hub 2 Plus can control lights, electric locks, and roller shutters. Scenarios can be activated in response to security mode changes, alarm triggerings, or Button commands.

Protection of large premises with complex internal organization

Business centers, factories, and multi-story villas with outbuildings — Hub 2 Plus is ready to secure even the most complicated properties. The new hub controls up to 200 devices. Its radio signal range can reach up to 2,000 meters while the maximum radio network coverage can reach 35 km2. Hub 2 Plus can manage 25 security groups with a total number of 200 users. This allows security personnel to divide large premises into zones and clearly organize staff access.

Controlled with apps

We refused to add buttons to our control panel and to use archaic interfaces. Apps are more comfortable and safe. They connect to a hub using a secure channel with Ajax Cloud — our server solution located at several AWS data centers. Apps allow users to control security, edit hub settings, configure connected devices, create scenarios, and monitor events. From a smartphone or PC. While on-site or away.

Tech specs:

Classification: Security system control panel with four in-built channels for external communication and support of detectors with photo cameras

Installation: Indoors

Connected devices: 200

Video surveillance support: 100 cameras and DVRs

Users: 200

Rooms: 50

Security groups: 25

Connected ReX: 5

Scenarios: 64

Apps: iOS 11.0 and later, Android 4.4 and later

Communication channels: 2 SIM cards

2G (GSM900/DCS1800 (B3/B8),

3G (WCDMA 850/900/2100 (B1/B5/B8),

LTE (FDD B1/B3/B5/B7/B8/B20),

Wi-Fi (802.11 b/g/n).

Ethernet

Alarm signals: Delivery time: 0.15 sec

Notification types: SMS, call, push-notification

Switching between 2G, 3G, LTE: Instant

Switching between the SIM-cards: 4 minutes

CMS connectivity: CMS connectivity: Contact ID, SIA (DC-09), CMS software supporting visual alarms verification

Operating system: OS Malevich

Power supply: 110-240 V with pre-installed battery, 6 V with alternative 6V PSU power supply, Energy consumption from the 110-240 V grid — 10 W

Built-in back-up battery: Li-Ion 3 А·h, Ensures up to 15 hours of operation when using SIM card only

Jeweller radio technology: Communication range with detectors — up to 2,000 m in an open space,

Two-way communication between devices,

Operating frequencies — 868,0−868,6 MHz,

Self-adjusting RF output power — up to 25 mW,

Block encryption based on AES algorithm,

Detector polling period — 12−300 s,

Frequency hopping.

Wings radio technology: Transmission of visual confirmations, Delivery verification of packages

Operating temperature range: From −10°С to +40°С

Anti-sabotage: Forgery prevention

Notifications about jamming

Tamper to detect back lid opening and unmounting from SmartBracket

Dimensions: 163 × 163 × 36 mm

Weight: 351 g

Warranty: Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.

Complete set: Ajax Hub 2 Plus control panel, SmartBracket mounting panel, Power cable, Ethernet cable, Installation kit, SIM card (depends on region), User’s guide

Service life: 10 years
